Scan Mode:  HD Mode

Fast Mode

Light Source: HD Mode: Infrared MEMS

                    Fast Mode: Infrared VCSEL

Point Distance:  HD Mode: 0.05mm～3mm

                        Fast Mode: 0.5mm~10mm

Capture Frame: HD Mode: up to 15 fps

                        Fast Mode: up to 20fps

Working Distance: HD Mode: 100-350mm

                           Fast Mode: 270-1500mm

IR Camera Resolution: HD Mode: 2MP

                                 Fast Mode: 1.3MP

Align Mode:  Feature; Texture; Markers; Hybrid

Color Camera Resolution:  48 MP

Output Formats:  ply; stl; obj; asc

Outdoor Scan:  Yes

Scanner Body Weight:  Limited edition : 643g;

                                  Regular edition : 535g

Scanner Size:  180mm*95mm*26.5mm

                               (L*W*H)

CPU:  8-core CPU, 2.4GHz

RAM:  32 GB LPDDR4 Memory

Internal Hard Drive:  32GB eMMC + 512GB SSD

Power Charger:  65W fast charging, supports PD/PPS protocols

Interface:  Wi-Fi 6, USB Type C

Touchscreen:  6.4'' 2K OLED

Supplemental Light:  10

IMU:  6 DoF

Operating Temperature Range:  -10~40℃

Operating Humidity Range:  0 to 90% RH (non-condensing)

Packing Size:  380*305*155mm

Protection Grade:  IP50

Battery:  Built-in 5000mAh；

External power bank charging supported

Supported OS

No computer required for 3d scanning operation;

StarVision（Data processing program on PC）：Windows10/11(64-bit); macOS

Recommended PC configuration: Intel i7, 32 GB RAM; macOS 11.0 ( on Apple chip )
